Home > Products > Conference Reservation System

Conference Reservation System

Hitrolink conference reservation system is an advanced conference solution for organizations, which can support three meeting booking modes, schedule management, two meeting access methods, conference room status management, and information display.
SPECIFICATIONS
  • Software Interface
  • Room Panel Design
  • Server Design and Interfaces
SPECIFICATIONS
  • HTI-Display10/13 Series
    OS
    Android 5.1.1
    Processor
    Arm Cortex-A17 Mali-T764 GPU
    Memory
    2GB
    Storage（EMMC）
    16GB
    TF card
    Up to 32GB
    Touch screen
    IPS 10.1-inch 1920 * 1200/IPS 13.3-inch 1920 * 1200 (viewing angle 89/89/89/89)13.3 inch 10-point touch capacitive screen
    Wi-Fi
    WiFi IEEE 802.11b/g/n
    Bluetooth
    V2.1+EDR、V3.0+HS
    Speaker
    1W，8Ω
    LED
    Four circles of light band (red, green and yellow)
    POE
    36~58V DC In，IEEE802.3af
    RFID
    ID：125K；IC：13.56M
    Zigbee gateway
    Support ZigBee sensor with gateway function (optional)
    Timing switch
    Support
    Camera
    500W HD face recognition camera
  • HTI-Meeting-OA
    CPU
    Intel Apollo N3450 I5
    Main frequency
    2.2GHz
    Storage
    16GB RAM+64GB EMMC 128GB SSD
    Bluetooth
    4.2
    Interface
    USB3.0 * 2 HDMI2.0*1 LAN port * 1 DC IN*1
  • HTI-Smart-OS
    Communication Protocol
    Based on ZigBee HA Protocol
    Detection Technology
    PIR & Microwave
    Status Display
    The red light is always on when sense human
    Transmission Protocol
    IEEE 802.15.4
    RF Characteristics
    2.4GHz 10dBm transmission power
    Detection Range
    Diameter 6 meters (when the installation height is 3.6 meters)
    Detection Angle
    120 degrees
    Installation Height
    2.5-4m
    Delay Control
    Min.:10sec±3sec; Max.:7min±2min
    Working Voltage
    4.5-6VD or battery powered
    Outline Specification
    85 * 64 * 22mm (L * W* H)
    LED
    1- device operation status indicator
    Interface
    1- Type-C interface
    Scenario
    Mainly used in the reception room and conference room of the office building
